Tesseract OCR for Xamarin (part 1)

If you’re thinking about getting image recognition into a Xamarin app check out this open source Tesseract OCR port I’ve put together for Xamarin. Few weeks ago this question was asked on StackOverflow and I was surprised to find that there is no free OCR for Xamarin (neither for iOS nor for Android). What developer does when he founds that there is nice and open-source library for other platforms but not for the platform he is working with? Of course he migrates the library. So I created wrappers for Tesseract OCR for Xamarin.iOS and Xamarin.Android and also for Xamarin.Forms. In this post I will give some details about the library, will show how to use it and will tell about some issues and workarounds.

Some history

The Tesseract engine was originally developed at HP in 1985 and was then released as open source in 2005. It has been sponsored by Google since 2006. This wrapper is base on two open-source builds – tess-two by Robert Theis and Tesseract OCR iOS by G8Production.

How to use

First of all you can use either the NuGet package or the source code. This is not the “final stable” version, just one of the first ones. But I’m working on adding features and fixing bugs so if something is broken try getting the last available version. If it’s still broken don’t hesitate to post an issue on the GitHub.

TL;DR

You can find few samples here.

Long story

One of the main ideas I kept in mind is that whichever platform (Android/iOS/Forms, sorry no Windows Phone this time) you are working with, you can use same API and have access to all Tesseract engine features.

Let’s do it step by step.
1. Import your tessdata folder (you can download one or any number of languages from https://code.google.com/p/tesseract-ocr/downloads/list) into your application’s resources folder. For Android tessdata folder should sit under the Assets folder and all files should have Build action set to AndroidAsset. For iOS folder with files marked as BundleResource should be in the Resources folder.
2. Instantiate the API.

//for iOS
ITesseractApi api = new TesseractApi ();
//for Android
ITesseractApi api = new TesseractApi (context);

I personally prefer to use XLabs.IoC.Autofac though. This is the only step that can be done only in platform-specific assemblies. All other steps are platform-agnostic and can be done in a PCL or in a shared  projects.
3. Initialise Tesseract engine.

bool initialised = await api.Init ("eng");

You can use more than one language at a time. Just import all respective files to your tessdata folder and pass list of languages to the Init method (e.g. “eng+rus+esp”).
4. Recognise an image.

bool success = await api.SetImage (source);
if (success)
{
    string textResult = api.Text;
}

You can use System.IO.Stream, byte[] or image path as a source. On Android keep in mind that you need the image should be a valid Bitmap and not a YUV image (here you can find how to convert YUV to a Bitmap).
5. Read results. Apart from getting all the text as a single string you can also get a list of blocks, paragraphs,text lines, words or symbols.

bool success = await api.SetImage (source);
if (success)
{
    List<Result> words = api.Results (PageIteratorLevel.Word);
    List<Result> symbols = api.Results (PageIteratorLevel.Symbol);
    List<Result> blocks = api.Results (PageIteratorLevel.Block);
    List<Result> paragraphs = api.Results (PageIteratorLevel.Paragraph);
    List<Result> lines = api.Results (PageIteratorLevel.Textline);
}

Each Result contains text, it’s coordinates and result confidence so you can decide if you trust it or not (from my experience if confidence is less than 70% this result has nothing to do with the actual text).
6. Magic.
This text is perfect for the Tesseract engine.

Sample 1

The quick brown fox
jumped over the 5
lazy dogs!

Surprisingly this text is not bad as well.

ABCDE FGHI JKLHN OPQR STUVVJXYZ

ABCDE FGHI
JKLHN OPQR
STUVVJXYZ

This text is good, too.

the quick brown fox jumps over the lazy dog- THE QUICK BROlLIN FOX JUMPS OVER THE LAZY DOG.

the quick brown fox
jumps over the lazy dog
THE QUICK BROlLIN FOX
JUMPS OVER THE LAZY DOG.

7. No magic.
This is an open-source OCR library not a magical box converting any image to text. Here are some sample images and outputs to give you an idea of that you can get by using Tesseract engine.

Good font for the OCR mfizufrfomfiv rfie DC’R m m“ {mu mom Good font size for ocn

Good font for the OCR
mfizufrfomfiv rfie DCR
m m“ {mu mom
Good font size for ocn

You can see that same image with the different contrast can give absolutely different result. Hence you should prepare you image before processing it.

1

1

POSTAG E PAI D AU STRALI A

POSTAG E
PAI D
AU STRALI A

You can see that Tesseract is a powerful and open-source OCR engine and now you can go ahead and easily include it in your Xamarin app. In the next post I’ll tell you about TesseractApi settings and give some tips and tricks to improve recognition quality.
